Backboard 39 x 54 fan fiberglass, 1 5/8 in. thick | Backboard 42 x 60 rectangular steel, 10 ga. skin | Backboard ½ in. acrylic, approx. 60 x 36 | Backboard 40 x 54, ½ in. tempered glass | Backboard ½ in. tempered glass, 36 x 62 short board | Backboard ½ in. tempered glass, 48 x 72 perimeter |
Backboard frame Fiberglass laminates over high-density pressed-wood core | Backboard frame ¼ in. struts, 3/16 in. center rim support channel | Backboard frame Clear anodized aluminum "L" extrusions | Backboard frame Aluminum extrusion with corner brackets | Backboard frame Aluminum extrusion, pre-drilled for FT72C padding | Backboard frame Aluminum extrusion, 42 x 62 tall-board corner brackets |
Rim / goal Flexible institutional, 5/8 in. ring, 18 in. I.D. | Rim / goal Flexible institutional, 5/8 in. ring, 18 in. I.D. | Rim / goal Flexible institutional, 5/8 in. ring, 18 in. I.D. | Rim / goal Flexible institutional, 5/8 in. ring, 18 in. I.D. | Rim / goal 5/8 in. steel breakaway, 18 in. I.D., wire netlock | Rim / goal 5/8 in. breakaway, Flush-Mount™, 18 in. I.D. |
Breakaway mechanism — | Breakaway mechanism — | Breakaway mechanism — | Breakaway mechanism — | Breakaway mechanism Positive lock, single return spring, two steel balls | Breakaway mechanism Positive lock, heavy-duty spring, ball/detent |
Rim backplate & support — | Rim backplate & support — | Rim backplate & support — | Rim backplate & support Bolts through tubular steel bushings, cushioned plates | Rim backplate & support 3/16 in. backplate, ¼ x 1½ brace, 50% ring support | Rim backplate & support ¼ in. backplate, ¼ x 1½ brace, 60% ring support |
Mounting pattern — | Mounting pattern 20 x 35 board; 5 x 5 rim | Mounting pattern 20 x 35 H-frame slots | Mounting pattern 5 x 5 rim pattern | Mounting pattern 36 x 62 board corners; 5 x 4 rim | Mounting pattern 42 x 62 board corners; 5 x 5 rim |
H-frame Solid square tubing with black powdercoat finish | H-frame Solid square tubing | H-frame 1½ in. sq. 11 ga., 36 in. tall, 3/16 in. faceplate | H-frame aluminum extrusion with corner brackets | H-frame Solid square tubing with black powdercoat finish | H-frame — |
Extension & structure 48–72 in.; welded 2 in. sq. tubing, 1¾ in. extensions | Extension & structure 48–72 in.; welded 2 in. sq. tubing, 1¾ in. extensions | Extension & structure 48–72 in.; welded 2 in. sq. tubing, 1¾ in. extensions | Extension & structure 48–72 in.; welded 2 in. sq. tubing, 1¾ in. extensions | Extension & structure 48–72 in.; welded 2 in. sq. tubing, 1¾ in. extensions | Extension & structure 48–72 in.; welded 2 in. sq. tubing, 1¾ in. extensions |
Wall attachment (3) 2 x 8 yellow pine boards; 800# chain, turnbuckle | Wall attachment (3) 2 x 8 yellow pine boards; 800# chain, turnbuckle | Wall attachment (3) 2 x 8 yellow pine boards; 800# chain, turnbuckle | Wall attachment (3) 2 x 8 yellow pine boards; 800# chain, turnbuckle | Wall attachment (3) 2 x 8 yellow pine boards; 800# chain, turnbuckle | Wall attachment (3) 2 x 8 yellow pine boards; 800# chain, turnbuckle |
Standards, warranty & origin Lifetime limited warranty; made in USA | Standards, warranty & origin Lifetime limited warranty; made in USA | Standards, warranty & origin Lifetime limited warranty; made in USA | Standards, warranty & origin Lifetime limited warranty; made in USA | Standards, warranty & origin NCAA & NFHS; lifetime limited; made in USA | Standards, warranty & origin NCAA & NFHS; lifetime limited; rim made in USA |
Availability In stock - ready to ship | Availability In stock - ready to ship | Availability In stock - ready to ship | Availability In stock - ready to ship | Availability In stock - ready to ship | Availability In stock - ready to ship |
Ship Weight 410 lbs | Ship Weight 453 lbs | Ship Weight 390 lbs | Ship Weight 453 lbs | Ship Weight 493 lbs | Ship Weight 513 lbs |
Best for Budget-minded programs wanting a durable fan-shaped fiberglass board. | Best for High-abuse gyms and camps needing an indestructible steel backboard. | Best for Side courts and practice bays needing an economical 60 x 36 acrylic board. | Best for Practice courts wanting compact ½ in. glass with cushioned rim mounting. | Best for Competition gyms wanting NCAA-legal ½ in. glass with a breakaway rim and padding-ready frame. | Best for Gyms using a full 48 x 72 tall glass board with Flush-Mount breakaway rim. |
| $3,449.00 $3,289.00 | $3,424.00 $3,323.00 | $3,533.00 $3,428.00 | $3,682.00 $3,606.00 | $3,750.00 $3,672.00 | $4,276.00 $3,718.00 |
