Overall Height 20 ft. nominal; 20'-2" structure, 19'-10" above field | Overall Height 20 ft. | Overall Height 29'-10" | Overall Height 30 ft. nominal; 29'-10" above field level | Overall Height 40'-0" | Overall Height 40'-0" |
Main Pole One-piece welded 3-1/2" O.D. SCH 40 steel | Main Pole One-piece welded 3-1/2" O.D. SCH 40 steel | Main Pole 2-piece 5" SCH 40, 5-9/16" O.D. steel pipe | Main Pole 2-piece 5" SCH 40, 5-9/16" O.D. steel pipe | Main Pole 2-piece 6-5/8" O.D. SCH 40 steel pipe | Main Pole 2-piece 6-5/8" O.D. SCH 40 steel pipe |
Wing Panel 18" x 60" x 2", 11 ga. steel sheet metal | Wing Panel 18" x 60" x 2", 11 ga. steel sheet metal | Wing Panel 18" x 60" x 2", 11 ga. perforated steel | Wing Panel 18" x 60" x 2", 11 ga. perforated steel panel | Wing Panel 18" x 60" x 2", 11 ga. perforated steel panel | Wing Panel 18" x 60" x 2", 11 ga. perforated steel panel |
Panel Position — | Panel Position — | Panel Position — | Panel Position 20'-0" visible panel, bottom at 9'-10" | Panel Position — | Panel Position — |
Mounting / Installation Surface mount, adjustable leveling plate; wall-top OK | Mounting / Installation Semi-permanent ground sleeve or wall-top install | Mounting / Installation Permanent or semi-permanent | Mounting / Installation Permanent or semi-permanent | Mounting / Installation Surface mount with adjustable leveling plate | Mounting / Installation Permanent and semi-permanent |
Ground Sleeve / Hardware — | Ground Sleeve / Hardware Ground sleeve FPS-20 | Ground Sleeve / Hardware Ground sleeve FPS-30P plus anti-rotation hardware | Ground Sleeve / Hardware Ground sleeve FPS-30P (semi-permanent) | Ground Sleeve / Hardware — | Ground Sleeve / Hardware Ground sleeve FPS-40 with anti-rotation hardware |
Wind Rating Up to 120 MPH | Wind Rating Up to 150 MPH | Wind Rating Up to 150 MPH | Wind Rating Up to 150 MPH | Wind Rating Up to 130 MPH | Wind Rating Up to 130 MPH |
Typical Footing — | Typical Footing — | Typical Footing Shown footing based on 100 MPH wind; concrete/rebar by others | Typical Footing Permanent 72" deep; semi-permanent 48" deep | Typical Footing 54" dia. x 72" deep concrete (90 MPH basis) | Typical Footing 54" dia. x 72" deep concrete (90 MPH basis) |
Finish Powder coated yellow over zinc undercoating | Finish Powder coated yellow over zinc undercoating | Finish Powder coated white over zinc rich primer | Finish Powder coated yellow over zinc rich primer | Finish Powder coated yellow over zinc rich primer | Finish Powder coated yellow over zinc rich primer |
Color Options Yellow standard; white or orange optional | Color Options Yellow (standard), white, orange | Color Options White or orange | Color Options Yellow standard; white or orange optional | Color Options Yellow standard; white or orange optional | Color Options Yellow standard; white or orange optional |
Ship Weight | Ship Weight 602 lbs | Ship Weight 800 lbs | Ship Weight 800 lbs | Ship Weight | Ship Weight |
Best for Programs bolting a 20 ft. pole to an existing slab or outfield wall top. | Best for Fields needing a removable 20 ft. foul pole set in a ground sleeve. | Best for Facilities matching a white 30 ft. pole to light-colored outfield walls. | Best for Competition fields wanting a taller 30 ft. yellow pole with sleeve option. | Best for Stadiums surface-mounting a 40 ft. pole on a poured concrete footing. | Best for Elite venues wanting a 40 ft. pole removable via FPS-40 ground sleeve. |
| $7,270.00 | $5,774.00 | $12,607.00 | $11,340.00 | $21,012.00 | $17,270.00 |
